17
CUTTING DECKS, DEFLECTORS
ITEM PART NO. DESCRIPTION
1 7-3434 COVER, Spindle
2 6-1970 DECK, 28” (Painted w/decals)
-- 6-1971 DECK, 30” (Painted w/decals)
-- 6-1972 DECK, 33” (Painted w/decals)
3 6-0480 KIT, Air Lift (25”, 28” & 33” Deck)
(incl. items 4 thru 7)
-- 6-0735 KIT, Air Lift (30” Deck) (incl.
items 4 thru 7)
4 3-7723 AIR-LIFT (2) (25”, 33” Deck)
-- 3-1724 AIR-LIFT (2) (30” Deck)
5 9-0228 SCREW, 5/16-24 x 11/16”
Machine (6)
6 9-0391 WASHER, 5/16” Internal
Tooth Lock (6)
7 9-0223 NUT, 5/16-24 Hex (6)
8 5-2555 DEFLECTOR, 28”/33” Deck Discharge
(includes items 9, 10, 11, 12, 14)
9 2-6831 DECAL, Danger
10 3-3780 HINGE, Deflector (16” long)
10A 2-4569 HINGE, Deflector (8” long)
11 1-6341 SPRING, Hinge (use with 2-6234 Pin)
11A 1-6428 SPRING, Hinge (use with 2-6846 Pin)
12 2-6234 PIN, Hinge ( L-shaped) (16-1/4” long)
12A 2-6846 PIN, Hinge (straight) (8-7/8” long)
13 9-1070 NUT, 5/16-18 Hex Flange Lock
14 2-6483 NUT, 1/4” Push (2)
15 9-0584 BOLT, 1/4-20 x 1/2” Hex Fl. Lock
16 5-2553 DEFLECTOR, 30” Discharge
(incl. items 9, 10A, 11A, 12A)
17 9-1296 WASHER, 5/16” Flat (2)
18 9-0392 SCREW, 1/2-20 x 1” Hex
Head Cap, Grade 5 (2)
19 9-0509 WASHER, 1/2” Internal Tooth
Lock (2)
20 9-0559 NUT, 1/2-20 Hex Jam (2)
21 9-1508 BOLT, 5/16-18 x 3/4” Short
Neck Carriage, Grade 5 (2)
22 9-1016 SCREW, 1/4-20 x 5/8” Hex
Washer Self-Tap (4)
23 9-1510 BOLT, 5/16-18 x 1/2” Hex
Washer Self-Tap Gr. 5 (3)
24 9-1525 BOLT, 5/16-18 x 1/2” Hex
Flange Lock (2)
ITEM PART NO. DESCRIPTION
25 9-0613 NUT, 3/18-16 Hex Flange Lock
(9)
26 3-3570 BRACKET, Gage Wheel (Front)
(28” & 33” Decks)
27 9-1532 SCREW, 3/8-24 x 3-3/4” Hex
Head Cap, Grade 5 (3)
28 1-9190 WHEEL, Gage (3)
29 1-5272 SPACER (3)
30 9-1518 NUT, 3/8-24 Hex Nyloc (3)
31 3-3571 BRACKET, Gage Wheel (Rear)
(2) (28” & 33”Decks)
32 9-0731 BOLT, 5/16-18 x 1/2” Carriage
(6) for 28 & 33”, (8) for 30” Deck
33 9-1070 NUT, 5/16-18 Hex Flange Lock
(8) for 28 & 33”, (10) for 30” Deck
34 9-1015 SCREW, 1/4-20 x 3-1/2” Hex Washer
Self-Tap (2)
35 9-0492 WING-NUT, 5/16-18 (2)
36 9-0612 BOLT, 3/8-16 x 3/4” Hex Flange
Lock (3)
37 1-6983 COVER, 28” Mulcher
-- 1-6984 COVER, 33” Mulcher
38 9-0583 NUT, 1/4-20 Hex Flange Lock
Grade 5 (2)
39 3-4025 BRACKET, Anti-Scalp, 30” R.H.
40 3-4026 BRACKET, Anti-Scalp, 30” L.H.
41 3-4743 BRACKET, Anti-Scalp, 30” L.H.
42 3-4760 BRACKET, Anti-Scalp, 30” R.H.
43 2-6453 BLADE, Ninja 28”
-- 2-6565 BLADE, Ninja 30”
-- 2-4741 BLADE, Ninja 33”
44 1-6980 BLADE, 28” Mulcher
-- 1-6982 BLADE, 33” Mulcher
45 3-5635 28” BLADE (High Lift)
-- 1-8069 30” BLADE
-- 3-4168 33” BLADE (High Lift)
46 1-9515 28” BLADE
-- 1-9523 33” BLADE
R. E. RIDER SERIES 22 MANUAL No. 06128
