A38E – 514252-201
i
General Information
About This Manual
This manual covers A38E aerial platforms. Information
is included for machines that have been manufactured
to conform to all applicable requirements of the following
organizations:
y American National Standards Institute (ANSI)
y Canadian Standards Association (CSA)
y European Committee for Standardization (CE)
y Australian Standards (AS) certication
Part pages include a drawing and a bill of material.
The bill of material lists the item number that is on the
drawing, the Snorkel part number, quantity used and a
description of the item.
Some callouts in the drawings may have a balloon with
two numbers. The top number is the item number and
the bottom number is the quantity of the item at that
location.
While Snorkel has attempted in every way to conrm that
all information in this manual is correct, improvements
are being constantly made to the machine that may not
be reected in this manual.
If you nd information in this manual that is not correct
or is confusing, you are urged to report your ndings to
Snorkel for our evaluation. Your input is important to us
and will be used in future printings of this manual.
This machine is covered by a limited warranty that spe-
cically identies items warrantied by Snorkel and those
items covered by original manufacturer's warranty. A
copy of the Snorkel Limited Warranty is located on the
inside of the back cover of this manual.
Repairs and Maintenance
Every person who maintains, inspects, tests or repairs
the machine must be qualied and authorized to do so.
Caution
Do not modify this aerial platform without prior
written consent of Snorkel Engineering Department.
Modication may void the warranty, adversely affect
stability or affect the operational characteristics of
the aerial platform.
Abbreviations
The following abbreviations may be used in this manual.
AC alternating current
ANSI American National Standards Institute
AR as required
CCA cold cranking amps
cm centimeter
DC direct current
ft feet
GFCI ground fault circuit interruptor
in inch
lbs pounds
mm millimeter
no number
NPT national pipe thread
psi pounds per square inch
qty quantity
rpm revolutions per minute
UL Underwriters Laboratories Inc.
Additional Information
All correspondence relative to this machine, such as eld
reports, discrepancy reports, requests for information,
etc., should be directed to:
Snorkel North America
P.O. Box 1160
St. Joseph, MO 64502-1160 USA
Phone: 1-800-255-0317
Snorkel Europe
Vigo Centre
Birtley Road
Washington
Tyne & Wear
NE38 9DA
Phone: +44 (0) 845 1550 058
http://www.snorkellifts.com
