Snorkel A38E Parts And Service Manual

A38E – 514252-201
A38E Work Platform
When contacting Snorkel for service or parts information, sure to include the MODEL and SERIAL
NUMBERS from the equipment nameplate.
The Serial Number of the Work Platform is also stamped on the inside of the Chassis, close to the Steering Cylinder.
The A38E work platform meets and exceeds the requirements of both:
En280:2013+A1:2015 and ANSI A92.5 (1992)
SERVICE & PARTS
MANUAL
A38E
Aerial Work Platform
Nameplate
The Serial Number of the Work
Platform is also stamped on the
inside of the Chassis, close to the
Steering Cylinder.

Snorkel A38E Specifications

General

Model	A38E
Power Source	Electric
Battery	48V
Ground Clearance	6 in
Drive Speed	3.5 mph
Tire Type	Solid
Working Height	13.5 m (44 ft)
Platform Capacity	215 kg (475 lbs)
