A38E – 514252-201
ii
Left Side Front
Right Side Rear
Boom
Structure
Platform
Guardrails
Chassis
Upper
Controls
Entry
Bar
Battery Tray
Drive and Steer
Wheels
Groundstrap
Tie-Down/Lifting
Lugs
Electrical
Power Outlet (Optional)
Hydraulic Tray
Pump/Reservoir/Fluid Filter
Freewheeling
Brake Release
Valve
Entry
Step
Toeboards
Lower
Controls
Operator’s
Manual
Battery Charger
LED Charge Indicators
Tie-Down/Lifting
Lugs
Emergency Lowering Lever
Serial
Number
Battery
Disconnect
Battery
Charger
Receptacle
Battery Tray
Freewheeling
Brake Release
Valve
Component Identification
