GP400 I/O Allocations
GP400 I/O allocations Matrix I/O allocations
Pin Function Pin Function
P1-1 CAN1H MP1-1 Platform Mode B+ supply
P1-2 CAN1L MP1-2 Ground Mode
P1-3 GND MP1-3 CANH
MP1-4 GND
P9-1 RS232 B+ supply MP1-5 GND
P9-2 RS232 Rx MP1-6 CANL
P9-3 RS232 Tx
P9-4 RS232 Gnd MP2-1
Engine start
MP2-2
P4-1 Proportional Valve MP2-3
Steer left
P4-2 MP2-4
Steer right
P4-3 Ground Alarm MP2-5
Trigger (enable)
P4-4 Fwd MP2-6
Joystick (0.5V-2.5V-4.5V)
P4-5 Rev MP2-7
P4-6 High Speed Valve MP2-8
P4-7 Fuel run solenoid MP2-9
P4-8 MP2-10
Joystick supply
P4-9 Torque Mode MP2-11
Joystick supply
P4-10 MP2-12
Switch supply
P4-11
O/R Function enable
P4-12 MP3-1
MP3-1
P4-13 Lift down (gravity) MP3-2 MP3-2
P4-14 Brake release MP3-3 MP3-3
P4-15 Lift down (gravity) MP3-4 O/R AUTO RETRACT O/R AUTO EXTEND
MP3-5 O/R F/R RETRACT O/R F/R EXTEND
P5-1 RL up MP3-6 O/R F/L RETRACT O/R F/L EXTEND
P5-2 Steer Left MP3-7 O/R R/R RETRACT O/R R/R EXTEND
P5-3 Steer Right MP3-8 O/R R/L RETRACT O/R R/L EXTEND
P5-4 24V contactor MP3-9 LIFT SELECT DRIVE SELECT
P5-5 Lift up MP3-10 24VDC select
P5-6 Start relay MP3-11 HIGHSPEED SELECT COLD START Torque Select
P5-7 RR up MP3-12
MP3-12
P5-8 FR up
P5-9 FR Down MP4-1
Warning lamp
P5-10 MP4-2
Lift allowed lamp
P5-11 RR down MP4-3
Overload lamp
P5-12 Cold start relay MP4-4
Drive allowed lamp
P5-13 MP4-5
All alarm
P5-14 MP4-6
P5-15 RL down MP4-7
MP4-8
P6-1 Lift allowed lamp MP4-9
P6-2 Copy of "Torque Mode"
P6-3
P6-4 Overload lamp
P6-5
P6-6
P6-7 Axle release
P6-8
P6-9
P6-10 Axle release
P6-11
P6-12
P6-13 FL up
P6-14 FL down
P6-15 "not safe' Throttle
P7-1 From TBM POS (supply)
P7-2 Ground
P7-3 Enable
P7-4 Platform
P7-5 Start
P7-6 Cold Start
P7-7 24VDC Electric operation
P7-8 Lift UP
P7-9 Lift DOWN
P7-10
P7-11
P7-12
P7-13 Oil pressure
P7-14
P7-15 Alternator sense
P8-1 Engine Temperature
P8-2 Ezfit #1 input
P8-3
P8-4
P8-5 Ezfit #2 input
P8-6 Pressure transducer input
P8-7
P8-8
P8-9 From TBM # 3
P8-10
P8-11
P8-12 connect to P8-1
P8-13
P8-14 connect to TBM-
P8-15
P15-1
P15-2
P15-3
P15-4
P15-5
P15-6
P15-7
P15-8
P15-9 Height Limit 1
P15-10
P15-11
P15-12
P14-1 F/R outrigger Down
P14-2 F/L outrigger Down
P14-3 R/R outrigger Down
P14-4 R/L outrigger Down
P14-5 F/R outrigger Up
P14-6 F/L outrigger Up
P14-7 R/R outrigger Up
P14-8 R/L outrigger Up
P14-9 Axle switches
P14-10 Height Limit 2
P14-11
P14-12
