アイテム 部品番号 名前 数量 UOM
1 3603-05 PlainWasher 10 EA
2 3603-12 PlainWasher 33 EA
3 3610-05016 MetricBolt 4 EA
4 3610-06016 MetricBolt 4 EA
5 3610-12050 MetricBolt 8 EA
6 3611-12 MetricNylocNut 8 EA
7 3616-12040 MetricBoltGrade10.9 16 EA
8 3624-27 PermaglideBush 2 EA
9 3624-3 PermaglideBush 6 EA
10 3626-1 FlangedPermaglideBush 2 EA
11 3636 SplitPin 4 EA
12 8628 PinKeeper 4 EA
13 9311 Pin5/8"x53lg 1 EA
14 9319 Pin15x56lg 3 EA
15 11492-1 TabWasher 4 EA
16 12555-9 SteerAxleLowerPlate 2 EA
17 12556 SteeringTieRod 1 EA
18 12562 HubAdapter(Front) 2 EA
19 12563 Wheel/TyreAssembly-RHBlack 2 EA
20 12564 Wheel/TyreAssembly-LHBlack 2 EA
21 12570 WheelMotor 2 EA
22 13854 SteerHub-RH 1 EA
23 13855 SteerHub-LH 1 EA
24 13856 ThrustWasher-Steering 2 EA
25 13857 BearingRetainer 2 EA
26 98300-9 WheelNut 24 EA
27 100432-002 HydFitting-StraightORFS(04)-
SAE(04)
1 EA
28 512975-000 HydFitting-StraightORFS(08)-
SAE(12)
8 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Steer Assembly
Steer Assembly Wed Feb 24 00:49:09 UTC 2021 2-2
