Snorkel S39770RT - Page 16

アイテム 部品番号 名前 数量 UOM
1 3603-06 PlainWasher 2 EA
2 3603-12HD PlainWasher 3 EA
3 3603-16HD PlainWasher 9 EA
4 3605-06 SpringWasher 2 EA
5 3611-12 MetricNylocNut 2 EA
6 3611-16 MetricNylocNut 2 EA
7 3610-06016 MetricBolt 2 EA
8 3616-12090 MetricBoltGrade10.9 2 EA
9 3616-16130 MetricBoltGrae10.9 2 EA
10 3626-2 FlangedPermaglideBush 4 EA
11 011469-006 LugNut-5/8-18RH 9 EA
12 15092 Wheel/TyreAssembly-RH 1 EA
12 15093 Wheel/TyreAssembly-LHNon
Marking
1 EA
13 15094 SwingArm 1 EA
14 15095 WheelMotor 1 EA
15 15117 Cover-SwingArm 1 EA
16 15127 WasherPlate-DriveMotor 2 EA
17 100432-002 HydFitting-StraightORFS(04)-
SAE(04)
1 EA
18 100432-004 HydFitting-StraightORFS(04)-
SAE(06)
1 EA
19 100434-004 HydFitting-90ElbowORFS(04)-
SAE(06)
1 EA
20 100434-010 HydFitting-90ElbowORFS(06)
-SAE(08)
1 EA
21 100434-015 HydFitting-90ElbowORFS(08)
-SAE(12)
2 EA
22 116324-000 WheelGearbox 1 EA
23 0260070 O-Ring 1 EA
24 0260099 O-Ring 1 EA
25 5560245 Bolt 6 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Swing Arms Assembly
Swing Arms Assembly Wed Feb 24 00:49:09 UTC 2021 2-3
