GENERAL INFORMATION
General Information 1-1
REPAIR PARTS
Chassis Assembly 2-1
Steer Assembly 2-2
Swing Arms Assembly 2-3
Swing Arm Assembly After Serial Numbers S2770RT-07-200300598, S3370RT-07-200300602, S3970RT-
07-200500562 2-4
Wheel Mounting Assembly 2-5
Engine Cabinet Assembly 2-6
Engine Cabinet Assembly After Serial Numbers S2770RT-07-200900621, S3370RT-07-200900626,
S3970RT-07-200900582 2-7
Exhaust Extension 2-8
Radiator Guard Assembly 2-9
Hydraulic Cabinet Assembly 2-10
Hydraulic Cabinet After Serial Numbers: S2770RT-07-200900621, S3370RT-07-200900626 S3970RT-07-
200900582 2-11
Cabinets Assembly 2-12
V7 Stabiliser Assembly 2-13
Base, Stack, Platform Assembly 2-14
Base, Stack, Platform Assembly After Serial Numbers S3970RT-07-181100510, S3370RT-07-181100524,
S2770RT-07-181100530 2-15
Platform Assembly 2-16
Platform Assembly After Serial Numbers S2270RT-07-181100530, S3370RT-07-181100524, S3970RT-07-
181100510 2-17
Platform Rear Handrail Assembly 2-18
Emergency Bleed Down 3970, 3370 2-19
Emergency Bleed Down 2770 2-20
Scissor Stack Tees 2-21
Scissor Stack Assembly 3970 2-22
Scissor Stack Assembly 3370 2-23
Scissor Stack Assembly 2770 2-24
Angle Transducers Before Serial Numbers: S2770RT-07-200900617 S3370RT-07-200900626 S3970RT-07-
200900577 2-25
Angle Transducer After Serial Numbers S2770RT-07-200900617 S3370RT-07-200900626 S3970RT-07-
200900577 2-26
Kubota D902 T4 Diesel Engine Assembly 2-27
Plastic Fuel Tank Assembly 2-28
Steel Fuel Tank Assembly 2-29
Plastic Hydraulic Oil Tank Assembly 2-30
Steel Hydraulic Oil Tank, No Heater Assembly 2-31
Steel Hydraulic Oil Tank, With Heater Assembly 2-32
Placards And Decals 2-33
Placards and Decals Bi-Energy Machines 2-34
HYDRAULICS
