S2770RT-07-181100530, S3370RT-07-
190100529, S3970RT-190100519 5-6
LPG Engine Cabinet Radiator Guard Assembly
5-7
LPG Kubota WG752 Engine Assembly 5-8
Loom List 4-1
Lower Lift Cylinder 3-12
Main Manifold, No Fittings 3-2
Main Manifold, With Fittings 3-3
Maintenance 6-1
Placards And Decals 2-33
Placards and Decals Bi-Energy Machines 2-34
Plastic Fuel Tank Assembly 2-28
Plastic Hydraulic Oil Tank Assembly 2-30
Platform Assembly 2-16
Platform Assembly After Serial Numbers
S2270RT-07-181100530, S3370RT-07-
181100524, S3970RT-07-181100510 2-17
Platform Rear Handrail Assembly 2-18
Radiator Guard Assembly 2-9
STEER CYLINDER 3-10
Scissor Stack Assembly 2770 2-24
Scissor Stack Assembly 3370 2-23
Scissor Stack Assembly 3970 2-22
Scissor Stack Tees 2-21
Stabiliser Leg Cylinder Assembly 3-13
Steel Fuel Tank Assembly 2-29
Steel Hydraulic Oil Tank, No Heater Assembly
2-31
Steel Hydraulic Oil Tank, With Heater Assembly
2-32
Steer Assembly 2-2
Swing Arm Assembly After Serial Numbers
S2770RT-07-200300598, S3370RT-07-
200300602, S3970RT-07-200500562 2-4
Swing Arms Assembly 2-3
Upper Lift Cylinder Assembly 3-11
V7 Stabiliser Assembly 2-13
Wheel Mounting Assembly 2-5
Wiring Schematics 7-1
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Wed Feb 24 00:49:34 UTC 2021 A-2
