アイテム 部品番号 名前 数量 UOM
30 13086-03 RadiatorOverflowBottle 1 EA
31 13086-04 AirFilterAssembly 1 EA
32 13086-05 AirFilterBracket 1 EA
33 13086-06 OverflowAttachmentBracket 1 EA
34 13098 AirFilterSupport 2 EA
35 13099-1 RadiatorMount 2 EA
36 13106-2A FuelTankAssembly 1 EA
37 13806 FuseBlock-Bladex6 1 EA
37 13553-05 Fuse,Blade-5ATan 1 EA
37 13553-10 Fuse-HighRPM 1 EA
37 13553-15 Fuse,Blade-15ABlue 1 EA
37 13553-20 Fuse,Blade-20AYellow 1 EA
37 13553-25 Fuse,Blade-25AClear 1 EA
38 13869-01 CabinetHinge,LH 2 EA
39 13869-02 CabinetHinge,RH 2 EA
40 15106 SolenoidandCableAssembly-
Trombetta
1 EA
41 15107 CableAssembly-Throttle 1 EA
42 15108 ControlModule-Trombetta 1 EA
43 65004-008 RubberGrommet 1 EA
44 5560179 FlatWasher-Special 3 EA
45 8342416 LatchAdjustableTrigger,Key
508CH
1 EA
45 8342416-1 KEY508CH 1 EA
45 8342416-3 Latch-AdjustableTrigger,Key
508CH
1 EA
45 8342416-2 Key501CH 1 EA
46 13086-32 Radiator 1 EA
47 13086-31 IsolatorMount 4 EA
48 13872 RubberChannelSection 1 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Engine Cabinet Assembly
Engine Cabinet Assembly Wed Feb 24 00:49:11 UTC 2021 2-6
