アイテム 部品番号 名前 数量 UOM
1 3603-06 PlainWasher 28 EA
2 3605-06 SpringWasher 20 EA
3 3610-06012 MetricBolt 4 EA
4 3610-06016 MetricBolt 16 EA
5 3610-06110 MetricBolt 4 EA
6 3610-10035 MetricBolt 2 EA
7 3611-06 MetricNylocNut 4 EA
8 3626-8 FlangedPermaglideBush 2 EA
9 3633-3 RollPin 2 EA
10 11305 FootWeldInvertedStabiliserLeg 1 EA
11 11366-1 StabiliserBush 2 EA
12 11366-2 StabiliserBushSpacer 1 EA
13 11369 Pin7/8"x76mm 1 EA
14 11492-4 DualLocktab 1 EA
15 12036 Cylinder-StabiliserSR 1 EA
16 12036-5 SlidingSpacer 2 EA
17 12036-6 CompressionSpring 1 EA
18 14098-01 ProxMountBracket 8 EA
19 15085-03 AxleProx 2 EA
20 14098-03 HoseCover 4 EA
21 15048 InductiveProxNO 2 EA
22 100432-007 HydFitting-StraightORFS(06)-
SAE(04)
2 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
V7 Stabiliser Assembly
V7 Stabiliser Assembly Wed Feb 24 00:49:13 UTC 2021 2-13
