アイテム 部品番号 名前 数量 UOM
1 3603-16 PlainWasher 4 EA
2 3605-16 SpringWasher 4 EA
3 3606-06016 CountersunkSocketHeadScrew 8 EA
4 3610-10020 MetricBolt 2 EA
5 3610-16040 MetricBolt 4 EA
6 3624-19 PermaglideBush 4 EA
7 8626 PinKeeper 2 EA
8 15202 Pin,30mmx235 2 EA
9 11492-3 TabWasher 2 EA
10 11658-20 WearPlug 8 EA
11 13928 SlidingBlockWeld 2 EA
12 12566-2 WearPadSliderBlock(Bottom) 2 EA
13 12566-3 SliderBlockTop 12 EA
14 13931 SliderBarWeld 1 EA
15 13117-1 CounterweightFront 1 EA
16 13117-2 CounterweightRear 1 EA
17 13117-4 Strap,RearCounterweight 1 EA
18 13117-5 Strap,FrontCounterweight 1 EA
19 - BaseAssembly 1 EA
20 - BaseAssembly 1 EA
21 - BaseAssembly 1 EA
22 - BaseAssembly 1 EA
23 - BaseAssembly 1 EA
24 15201-09 SliderBlockShim0.9mm 2 EA
24 15201-12 SliderBlockShim1.2mm 2 EA
24 15201-16 SliderBlockShim1.6mm 2 EA
24 15201-20 SliderBlockShim2mm 2 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Base, Stack, Platform Assembly After Serial Numbers S3970RT-07-181100510, S3370RT-07-181100524, S2770RT-07-181100530
Base, Stack, Platform Assembly After Serial Numbers S3970RT-07-181100510, S3370RT-07-181100524, S2770RT-07-181100530
Wed Feb 24 00:49:14 UTC 2021 2-15
