アイテム 部品番号 名前 数量 UOM
29 8626 PinKeeper 2 EA
30 8926-1 PlugRHS25mm 4 EA
31 010076-000 ManualEnclosure 1 EA
32 11492-3 TabWasher 2 EA
33 11695 HandrailLatchLeft 1 EA
34 11695-3 LatchHoldingRing 2 EA
35 12709-10 RolloutDeckSlidePad 2 EA
36 12749 WristSupport 1 EA
37 13122-11 ExternalRoller 2 EA
38 13122-12 Stop-Rollout 2 EA
39 13122-14 WearPad-Internal 4 EA
40 13128 RolloutFrameWeld 1 EA
41 13132 PlatformFloorPressing 2 EA
42 13258 ExtensionStepWeld(2770) 1 EA
43 13259 ExtensionStepWeld(3370) 1 EA
44 13262 HandrailLeftFront 1 EA
45 13264 RightHandrail 1 EA
46 13268 LeftHandrail 1 EA
47 13525-05 Washer,M5 2 EA
48 13649 ExtensionStepWeld(3970) 1 EA
49 13786 RolloutDeckWeld 1 EA
50 13840 HandrailFront 1 EA
51 13841 HandrailRightFront 1 EA
52 13843-03 Handgrip-Black25mmID 1 EA
53 13875-01 HarnessBracket 3 EA
54 13921 ControlMount 1 EA
55 13935 PlatformWeld 1 EA
56 13941 Pin 2 EA
57 14023-04 UpperControlBox 1 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Platform Assembly
Platform Assembly Wed Feb 24 00:49:15 UTC 2021 2-16
