Snorkel S39770RT - Page 55

アイテム 部品番号 名前 数量 UOM
0 13912A HandrailAssembly,EntryEnd 1 EA
1 3603-05 PlainWasher 4 EA
2 3603-08 PlainWasher 24 EA
3 3605-06 SpringWasher 12 EA
4 3610-06040 MetricBolt 6 EA
5 3610-06055 MetricBolt 6 EA
6 3611-05 MetricNylocNut 4 EA
7 3611-06 MetricNylocNut 12 EA
8 3613-05040 SocketHeadcapScrew 2 EA
9 3613-05055 SocketHeadCapScrew 2 EA
10 7495 SpringHinge 2 EA
11 8926-1 PlugRHS25mm 1 EA
12 13909 Latch,MagneticSlam 1 EA
13 13913 HandRail-Gate 1 EA
14 9980003 PIPEINSULCLOSEDCELLAP
ARMA
1 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Platform Rear Handrail Assembly
Platform Rear Handrail Assembly Wed Feb 24 00:49:15 UTC 2021 2-18
