Snorkel S39770RT - Page 63

アイテム 部品番号 名前 数量 UOM
1 3603-10 PlainWasher 4 EA
2 3610-10020 MetricBolt 2 EA
3 3610-10025 MetricBolt 27 EA
4 3610-10040 MetricBolt 2 EA
5 3611-10 MetricNylocNut 2 EA
6 3619-5 ExternalCirclip 24 EA
7 3624-19 PermaglideBush 40 EA
8 3624-2 PermaglideBush 72 EA
10 3629-5062L Washer,ScissorPivot 24 EA
13 8626 PinKeeper 30 EA
14 13667-16 Pin,30mm 4 EA
15 9292 Pin 4 EA
17 11492-3 TabWasher 31 EA
19 11804 ScissorPivotPin 12 EA
20 12566 SlidingBlockWeld 2 EA
22 13667-1 Arm,Outer,OddEnds,1"Female 4 EA
23 13667-32 Arm,First,OuterRightHand 1 EA
24 13667-33 Arm,Lower,InnerWeld 1 EA
25 13667-15 Arm,Inner,Top 2 EA
26 13667-16 Pin,30mm 20 EA
27 13667-37 Arm,Inner,DualCylinderWeld 1 EA
28 13667-1 Arm,Outer,OddEnds,1"Female 1 EA
29 13667-2 Arm,Outer,TopOddEnds,Left
Hand
4 EA
30 13667-2 Arm,Outer,TopOddEnds,Left
Hand
1 EA
31 13667-35 Arm,Outer,TopOddEnds,Right
Hand
1 EA
32 13667-36 Arm,Inner,UpperCylinderTop 1 EA
33 13667-15 Arm,Inner,Top 1 EA
34 11380 SafteyProp 1 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Scissor Stack Assembly 3970
Scissor Stack Assembly 3970 Wed Feb 24 00:49:17 UTC 2021 2-22
