アイテム 部品番号 名前 数量 UOM
1 13906-01 LowerLiftCylinder 1 EA
2 9292 Pin 4 EA
3 3610-10020 MetricBolt 4 EA
4 11492-3 TabWasher 20 EA
5 8626 PinKeeper 20 EA
6 3610-10120 MetricBolt 1 EA
7 3603-10 PlainWasher 4 EA
8 3611-10 MetricNylocNut 1 EA
9 11380 SafteyProp 1 EA
10 3606-06025 CountersunkSocketHeadScrew 2 EA
11 11143-2 WearPad 1 EA
12 3603-06 PlainWasher 2 EA
13 3611-06 MetricNylocNut 2 EA
14 3629-5062L Washer,ScissorPivot 20 EA
15 11804 ScissorPivotPin 10 EA
16 3619-5 ExternalCirclip 20 EA
17 13574-16 Pin,30mm 16 EA
18 3610-10025 MetricBolt 16 EA
19 13667-1 Arm,Outer,OddEnds,1"Female 5 EA
20 13667-36 Arm,Inner,UpperCylinderTop 1 EA
21 13667-2 Arm,Outer,TopOddEnds,Left
Hand
4 EA
24 13667-33 Arm,Lower,InnerWeld 1 EA
25 13667-32 Arm,First,OuterRightHand 1 EA
26 13667-15 Arm,Inner,Top 2 EA
27 13667-36 Arm,Inner,UpperCylinderTop 1 EA
28 3624-2 PermaglideBush 60 EA
29 3624-19 PermaglideBush 40 EA
30 13906-02 UpperLiftCylinder(NotShown) 1 EA
31 12241-2 PinSpacer 1 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Scissor Stack Assembly 3370
Scissor Stack Assembly 3370 Wed Feb 24 00:49:17 UTC 2021 2-23
