アイテム 部品番号 名前 数量 UOM
0 15141-01 HydraulicTankAssembly 1 EA
1 3603-06 PlainWasher 10 EA
2 3611-06 MetricNylocNut 10 EA
3 3618-11 HoseClamp11-25mmZP 1 EA
4 7024-002 Adapter3/4>3/4 1 EA
5 7024-003 Adapter11/6>11/16 1 EA
6 7024-005 Adapter15/6>15/6 1 EA
7 7084-005 DowtySeal-1/4"BSP 1 EA
8 11430-1 BasePlateWeld 1 EA
9 11430-5 Gasket 1 EA
10 11487 FilterBreather 1 EA
11 11558-1 Tank13Gal 1 EA
12 15130-01 TopPlateHydraulicOilTank 1 EA
13 15153-12 Washer,Flat3/4 1 EA
14 15153-16 Washer,Flat1" 1 EA
15 15156-14 Washer,FlatM14 1 EA
16 452756 Plug,Magnetic3/8NPT 1 EA
17 605256 Cap,Vented 1 EA
S2770RT S2770BE S3370RT S3370BE S3970RT S3970BE VERSION 7 PARTS MANUAL
Plastic Hydraulic Oil Tank Assembly
Plastic Hydraulic Oil Tank Assembly Wed Feb 24 00:49:20 UTC 2021 2-30
