Chapter 2 – Specifications
TB42/TB50 – 0075251EE 5
Working Envelope – TB50
Meters
(Feet)
9.1
(30)
6.1
(20)
3.0
(10) 0
3.0
(10)
12.2
(40)
0
3.0
(10)
6.1
(20)
9.1
(30)
12.2
(40)
15.2
(50)
18.2
(60)
