19
Function (00) Instant door open:
Authorized personnel could get into the setup mode to open the door when any emergency
cases happened.
6. Reader installation instructions
(1)Reader connector
Note: (1) Door open relay electrical rating is 2A/24 VDC, 1A/120VAC
(2) Push button door open / door sensing / anti-theft sensing all are connection
terminal. Any other power supplying is not allowed.
(3) In order to avoid any disturbance of read range, user is advised to use two
separate adaptors.
Queuing for door
open input.
OPEN DOOR
YES => “
＃
“
Key in 00
Key in
＃
or
＊
Esc system function selection
Press other key
Go into function 00
Key in the ＃
SYSTEM FUNCTIONS
SELECTION : _ _
status light on, display
function selection.
Key in
＃
system password
＃
Go into system function setup.
back to system function selection.
Setting successfully,
beep sound occurred.
Yellow
Purple
Blue
Green
Brown
Red
Purple
Blue
Green
Yellow
Orange
Brown
Black
Red
Push button door open joint terminal
Door open relay (Common) terminal
Door open relay (Normal Close) terminal
Door open relay (Normal Open) terminal
Signal (data) receiver
Signal (data) transmitter
Input power, negative GND
Input power,positive 12V
6 PIN CONNECTOR
8 PIN CONNECTOR
GND
Anti-duress output terminal (low active)
Alarm output point terminal (low active)
Door sensing terminal 2
Door sensing terminal 1
Anti theft sensing terminal (low active)
ST680 Wiring diagram
Yellow
Purple
Blue
Green
Brown
Red
Purple
Blue
Green
Yellow
Orange
Brown
Black
Red
Push button door open joint terminal
Door open relay (Common) terminal
Door open relay (Normal Close) terminal
Door open relay (Normal Open) terminal
Signal (data) receiver
Signal (data) transmitter
Input power, negative GND
Input power,positive 12V
6 PIN CONNECTOR
8 PIN CONNECTOR
GND
Anti-duress output terminal (low active)
Alarm output point terminal (low active)
Door sensing terminal 2
Door sensing terminal 1
Anti theft sensing terminal (low active)
ST680 Wiring diagram
