6.3 How to install the greasing system
The hammer can be equipped with a lubrication system. For the installation of the
lubrication system, it is necessary to follow the above scheme. The hoses of the
grease (input and output) have to be linked to the greasing pump. In order to have a
correct installation, please read and follow the manual supplied by the lubrication
system’s manufacturer.
G = grease
P = pump input
T = tank
REGULATIONS AND GREASING SYSTEM
