3 Transportation and installation
The personnel in charge of freighting and installing the machine must
be acquainted with the following instructions.
Pay careful attention to the weight of the hammer.
3.1 Freight
Always move with care: each inappropriate movement can be very
dangerous.
Do not pass or stop under the hammer when it is lifted up.
3.2 Hammer Hoses connection
Connect pressure line hose to the entry side IN
Connect returne line hose to the exit side OUT
Check in the technical specification
paragraph, the total weight of the hammer,
including the adapting plate and the tool
already mounted.
In order to move the hammer safely, when
it is not coupled to the excavator, it is
necessary to have a suitable and safe
lifting system (as showed in the picture on
the right).
Always use means of transport and lifting
that are suitable to the weight of the
hammer.
