2.5 The accumulator
MDO 1600 ACCUMULATOR SCREWS
V.L. = Long Screws
BLOCK SIDE
It’s necessary to unscrew the long screws in order to remove the
accumulator from the monoblock.
You will find here below the accumulator details with the long screws to be
unscrewed highlighted.
