The above mentioned parameters are based on tests according to international flashlight testing
standards (ANSI/NEMA FL1) using one 3000mAh 18650 Li-ion battery in our laboratory. Results
may vary with different battery or under different environmental conditions.
Specifications
1 X High Power LED
Working Voltage: 2.7V - 4.2V
Battery Options: 1 X 18650 Li-ion battery
Dimension: 101.5mm (length) × 24.7mm (head diameter)
Weight: 55g (without battery)
Flashlight body: Aerospace grade 6061 grade aluminum alloy
USB Type-C Charging
Mode Memory: memorizes the last brightness level used in the general modes (except Moon, Turbo
and Strobe)
Advanced Temperature Regulation (ATR) technology: ATR will adjust the brightness level
automatically when the driver temperature reaches relatively high temperature to prevent overheating.
Reverse polarity protection: it cuts off the power while battery inserted improperly.
LVP: while on, if the battery voltage is lower than 2.7V, it turns off automatically.
HVP: while on, if the battery voltage is higher than 4.35V, it turns off automatically.
Battery Installation
Before first use, please unscrew the tailcap and remove the insulating film. If the battery needs to be
replaced, make sure that the positive end of the new battery faces the flashlight head when you put it in.
Battery Availability
Rechargeable Li-ion battery
Power Indicator
The power indicator shows the power status for 5 seconds after turning SC18 on.
Green = remaining battery level is good
Red = remaining battery power is poor.
Flashing Red = critical battery level, please replace or recharge your flashlight as soon as possible.
