3.2 Montage
Assemble your SO4 2ND GEN / SO4 PRO / SO4 PRO 2ND GEN
1. straighten the front bar as shown in the figure. Push the folding lever firmly as shown in the illustration to
lock the front bar. Please check the tyre pressure. The tyre pressure should be 2,5bar.
2. Insert the exposed cable into the front bar. Then insert the handle bar into the front bar as well. Use the tool and screws to bolt the
handlebar to the front bar.
3. After assembly, test whether the SO4 2ND GEN / SO4 PRO / SO4 PRO 2ND GEN can be switched on.
Folding / Storage of the SO4 2ND GEN / SO4 PRO / SO4 PRO 2ND GEN
Before folding the SO4 2ND GEN / SO4 PRO / SO4 PRO 2ND GEN, make sure that the scooter is switched off. Press the buckle as shown in the illustration and pull the lever down. Fold
the front bar down to the rear mudguard and lock the hook on the buckle on the mudguard.
