echochange – Quick Start
PLEASE READ THIS QUICK START CAREFULLY BEFORE USING THE PRODUCT!
FOR MORE INFORMATION CONSULT THE PRODUCT MANUAL.
Scope of Supply
The following list of components should be contained in the echochange package:
˃ echochange
˃ SD-Card
˃ CDROM with configuration software
˃ echochange Quick Start
Exemplary Use Case
Important Notes
˃ A power source 100-240V AC (EUR/UK/USA) / 24V DC for power supply is not included.
Please order it separately (700-5596-04).
Please mind the polarity when connecting the cable: black wire
+, white wire – .
˃ If you want to use your own connector power pack, please pay attention the polarity of the 24 V DC
terminals (positive pole above, minus pole below).
˃ Please note the pin and port description on the device labels.
