Software House RM SE Series User Manual

Installation
4
Reader Power Supply
Requirement
12 VDC, 300 mA maximum +/- 10%.
Standards
RM readers are Underwriters Laboratories Inc. (UL), Listed to Standard UL 294,
Access Control System Units, Seventh Edition.
RM readers are Underwriters Laboratories Inc. (UL), Listed to Standard UL
1076.
RM readers must be wired in accordance with the National Electrical Code
(ANSI / NFPA 70), local codes, and the authorities having jurisdiction.
Installation
This section describes installation and wiring.
Install the reader in the following order:
1. Install the reader mount plate.
2. Wire the components.
3. Following ESD Protection Requirements, connect and ground the cable
shields on the reader bus.
4. Set the reader address.
5. Install the ARM-1 relay boards (optional).
6. Mount the reader standard housing on the reader mount plate using the
Software House security screwdriver (Part number 132-183).
NOTE
Reader power to be supplied from power limited output of a Listed control
unit or from a separately-supplied UL Listed, access control (UL294) or
burglar alarm (UL603), power-limited power source with four-hour standby
capability.
Table 2. UL 294 7
th
Edition Performance Levels
Feature Level
Destructive Attack 1
Endurance 4
Line Security 1
Standby Power 1
