14 Installation Instructions
3 Installation Instructions
Z Whenever possible, install the heater on a wall beneath a window, but
never in a ventilation area.
Z Always observe the minimum safety distance between walls or
obstacles and the heater during installation (fig. 1).
Wall Mounting
1 Place the heater against the wall. Mark the installation position of the
heater using two pieces of masking tape. (fig. 2).
2 Mark the positions of the 4 holes to be drilled for fixing the top mounts
(fig. 3).
3 Drill the 4 holes and insert the wall plugs provided (fig. 4).
i Screw hole sizes: 6 mm in diameter x 30 mm in depth
4 Fix the top mounts (2) to the wall using the screws provided (fig. 5).
5 Fix the bottom mount (3) to the heater, screwing the supplied screw
(M5x20) through the circular hole.
i Fix the mount (3) on the edge of the central groove (fig. 6).
6 Suspend the heater from the top mounts (2). To do so, insert the
fastening pins of the top mounts into the fastening holes of the heater (5)
(fig. 7).
Z Ensure that the heater is horizontal.
7 With the heater in place, mark the position of the hole to be drilled for
fixing the bottom mount.
8 Drill the hole into the wall and insert the supplied wall plug (if necessary,
remove the heater so that you can work without obstruction, replacing it
when you have finished).
i Screw hole sizes: 6 mm in diameter x 30 mm in depth
9 Fix the bottom mount (3) to the wall using the screws provided (fig. 8).
Z To mount on a plastered brick wall, use the screws and wall plugs
provided. For other surfaces, consult the specialist salesperson.
Installing the Feet (Accessory - NOT included)
If you would like your heater to be free-standing, instead of wall-mounted (fig. 9):
1 Turn the heater over so that the base faces upwards.
2 Place the feet (6) on the support plates.
