100
• Fasten the bracket taking into consideration the safety distances (Appendix 1)
and safety and operating instructions.
• Unscrew the star grip nuts and hexagon nut from the threaded spindles
• Mount the heater while slightly bending the bracket
• On one side, screw the hexagon nut on to the threaded bolt and tighten against
the bracket
• Set the radiating angle as required
• Tighten the M6 nut with a 10 mm open-ended spanner.
• Screw the star grip nuts in place on both sides.
