SolarEdge ZigBee - Installing the ZigBee Antenna and Slave Module

Chapter 2: SolarEdge Repeater User Interfaces
ZigBee Repeater Installation Guide – MAN-01-00130-1.0
9
Figure 3: User Interfaces
Link LED (Yellow)
S_OK LED (Green)
Signal strength LEDs
(x3, Green)
USB Port
Power LED (Green)
Antenna
