SolarEdge ZigBee Installation Guide

Chapter 2: SolarEdge Repeater User Interfaces
ZigBee Repeater Installation Guide – MAN-01-00130-1.0
8
8
Chapter 2: SolarEdge Repeater
User Interfaces
The following interfaces are used in this product:

USB Connector - Connection to the power supply

LEDs - The repeater has four LED indicators, as follows:
Label and
Color
Indication
Functionality
S_OK
(green)
Communication
passing though this
device is received
by the SolarEdge
monitoring portal
ON - connection with
SolarEdge master device is
OK, and the master device is
connected to the server.
OFF - Communication with the
SolarEdge master device has
failed
Link
(yellow)
ZigBee RF
communication
with associated
master
ON - Connection with
SolarEdge master device is
OK.
OFF - Communication with the
SolarEdge master device has
failed
3x Signal
strength
(green)
Signal strength to
nearest ZigBee
device
(Low/Medium/High)
All 3 LEDs ON - High
Two LEDs ON - Medium
One LED ON - Low
Power
(green)
Power
Power supply connected to
the repeater
The other interfaces are not used in this product.
