1.1 Scope of Validity
This manual is an integral part of X3-PRO G2 Series. It describes the
assembly, installation, commissioning, maintenance and failure of the
product. Please read it carefully before operating.
Note: “X3” means three phases. ”PRO” means product series name. “8K”
means rated output power is 8 kW. ”G2” means this product is the second
generation machine of the series. “2D” means two strings of MPPT and with
DC switch. “3D” means three strings of MPPT and with DC switch.
Keep this manual at where it is accessible all the time.
1.2 Target Group
This manual is for qualified electricians. The tasks described in this manual
only can be performed by qualified electricians.
1.3 Symbols Used
The following types of safety instructions and general information appear in
this document as described below:
1 Notes on this Manual
7 Troubleshooting
7.1 Trouble Shooting
7.2 Routine Maintenance
8 Decommissioning
8.1 Dismantling the Inverter
8.2 Packaging
8.3 Storage and Transportation
8.4 Waste Disposal
Notes on this ManualContents
03
02
54
54
57
58
58
58
58
58
59
9 Disclaimer
* Warranty Registration Form
X3-PRO-20K-G2(2D)
X3-PRO-25K-G2(3D)
X3-PRO-17K-G2(3D) X3-PRO-20K-G2(3D)
X3-PRO-30K-G2(3D)
X3-PRO-8K-G2(2D) X3-PRO-10K-G2(2D) X3-PRO-12K-G2(2D)
X3-PRO-15K-G2(2D) X3-PRO-17K-G2(2D)
X3-PRO-15K-G2(3D)
Danger!
“Danger” indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Warning!
“Warning” indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
Caution!
“Caution” indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Note!
“Note” provides tips that are valuable for the optimal operation
of your product.
