INSTALLATION
5
2. INSERT BULB INTO CHAMBER:
IMPORTANT:
HANDLE THE LAMP BY THE ENDS ONLY AND AVOID TOUCHING THE CLEAR GLASS OF THE
LAMP. IF POSSIBLE USE COTTON GLOVES TO HANDLE LAMP TO AVOID GETTING OILS FROM
HANDS ON THE LAMP. SKIN OILS ATTACH TO THE LAMP AND SHORTEN ITS EFFECTIVE LIFE. IF
LAMP IS TOUCHED, WIPE CLEAN WITH A SOFT CLOTH AND RUBBING ALCOHOL.
THIS ULTRAVIOLET RADIATION APPLIANCE CONFORMS TO THE APPLICABLE PROVISIONS OF
THE CODE OF FEDERAL REGULATIONS (CFR) REQUIREMENTS, INCLUDING TITLE 21, CHAPTER 1,
SUBCHAPTER J, RADIOLOGICAL HEALTH
A. Unthread and remove the end cap with the wire attached from the end of the UV chamber, by first
loosening the small black plastic nut, then the larger black nut to pull out plug.
B. Pull gently until lamp is visible and unplug from each other.
C. Plug the 4 prong plug into the end of the UV lamp. If lamp is not fully plugged in, damage to the unit
may occur.
D. Slide lamp straight into chamber - Be careful, inserting the lamp at an angle, even a slight angle
can crack the quartz sleeve.
E. Rethread blue cap back onto chamber fitting very snug to assure tight seal. BE SURE ALL THESE
CONNECTIONS ARE SNUG. HAND TIGHTEN ONLY!
C
D E
Quartz
sleeve
Push
snug
snug
BA
loosen
first
loosen
second
DO NOT
LOOSEN
Insert bulb carefully
snug
To Next Page
