REAR STABILIZER COVER HARDWARE STEP 2
1. Install the rear stabilizer cover with two Phillips Head Screws (91). Tighten using the
Combination M5 Allen Wrench & Phillips Head Screw Driver (86).
HANDLEBAR HARDWARE STEP 3
1. Install the handlebars with four Button Head Socket Bolts (88), Split Washers (49)
and Flat Washers (48). Tighten the bolts securely using the Combination M5 Allen
Wrench & Phillips Head Screw Driver (86).
#91. M5 x 10mm
Screw (2 pcs)
#49. ø8 Split
Washer (4 pcs)
#48. ø8 x 16mm
Flat Washer (4 pcs)
#88. M8 × P1.25 × 20L
Button Head Socket
Bolts (4 pcs)
