Solem WooBee - Valves Wiring

Validate
Select the Staon mode
Validate
Validate
Validate
Watering starts
Set the Staon
mode
Set the duraon
From 1 minute
to
12 Hours
Remaining watering me
Example of manuel command
Select
Find the details of the conguraon in the installaon guide
at hp://www.solem.fr or on the MySOLEM applicaon.
VALVES WIRING
Connect the valves
with 9V latching solenoids.
CP
Noir
Rouge
1 2 3 4 5 6
+ S - C P 1 2 3
4
