SOLICARD 4000
Installation guide UK
3
Technical specification
4000 Control unit
24V feeding KP-1:1&2 17-24V AC/DC
At 12V DC feeding KP-1:3&4 +12V = 3/0V = 4
Temperature range +5° – +40°C
Internal consumption
See Table 1
below
The table below shows the current consumption in 4000 when
communicating with DAC-30 (not running DAC-30).
DAC-30
1 2 3 4 5 6 7 8
24V to
4000CU
160
mA
170
mA
180
mA
190
mA
220
mA
230
mA
240
mA
250
mA
9 10 11 12 13 14 15 16
270
mA
280
mA
290
mA
300
mA
320
mA
330
mA
340
mA
350
mA
DAC-30
1 2 3 4 5 6 7 8
12V to
4000CU
190
mA
205
mA
220
mA
235
mA
270
mA
285
mA
300
mA
315
mA
9 10 11 12 13 14 15 16
350
mA
365
mA
380
mA
395
mA
430
mA
445
mA
460
mA
475
mA
Table 1
