SOLICARD 4000
Installation guide UK
4
DAC-30
24V feeding KP-1:1&2
17-24V AC/DC *
12V DC stabilized feeding KP-1:6&7 +12V = 6/0V = 7
Temperature range +5° to +40° C
DAC-30 current consumption
12V DC Max 130mA
24V DC Max 70mA
Current consumption relay card Approx. 30mA/relay
Relay current limitation 1A
Total 12V current consumption, i.e. electric strike,
reader and 12V regulated output
Max 0,7A (700mA)
Buzzer KP-2:17&18 Max 100mA
* When using a 24V electrical lock the DAC-30 shall be fed with 24V.
The table below shows the current consumption for the DAC-30 fed with
24V and with 1 or 2 readers connected.
Locked
mode
Unlocked
mode
Of that illumina-
tion in reader
DAC-30 fed with 24V 70mA 100mA
1 pcs. 6355MLB
II
110mA 160mA 15-20mA
2 pcs. 6355MLB
II
150mA 200mA 30-40mA
Table 2
The table below shows the current consumption for the DAC-30 fed with
12V and with 1 or 2 readers connected.
Locked
mode
Unlocked
mode
Of that illumina-
tion in reader
DAC-30 fed with 12V 100mA 120mA
1 pcs. 6355MLB
II
160mA 200mA 15-20mA
2 pcs. 6355MLB
II
230mA 280mA 30-40mA
Table 3
