SOLICARD 4000
Installation guide UK
6
6355MLB
II
Card reader
Voltage in 12V (from DAC-30)
Temperature range -40°C to +85° C
The tables below shows the current consumption for the reader connected
to DAC-30.
Normal Max
6355MLB
II
connected to DAC-30 that is fed with 24V 40mA 70mA
Table 6
Normal Max
6355MLB
II
connected to DAC-30 that is fed with 12V 70mA 120mA
Table 7
4 doors
1 pieces 4000CU, including one 4014LC loop card
4 pieces DAC-30
4-8 pieces 6355MLB magnetic card reader or similar
4 pieces TKN1/TKN2 Exit buttons
4 pieces Electric Strike
4 pieces Motor lock
1 pieces 2450PS or more if the system requires so
PC or Portable programmer
16 doors
1 pieces 4000CU, including one 4014LC loop card
3 pieces 4014LC Loop card
16 pieces DAC-30
16-32 pieces 6355MLB magnetic card reader or similar
16 pieces TKN1/TKN2 Exit buttons
16 pieces Electric Strike
16 pieces Motor lock
2 pieces 2450PS or more if the system requires so
PC or Portable programmer
There is also a relay card, 4016, which can be used to control three outputs
connected to optional relays (one card per control unit) to be used together
with the software for as an example alarm control.
