APPLIANCE DESCRIPTION
70 71
1. Front safety grid with frame ring, the remote control
can be mounted to the centre
2. Rotor blade nut
3. Rotor blade
4. Rear nut
5. Rear safety grid
6. Motor shaft on the motor casing
7. Frame ring fastener clip
8. Control panel with function buttons (On/Off, oscillation, speed)
9. Motor casing
10. Pillar
11. Pedestal with inlying cables
12. Remote control
Note: You can manually tilt the fully assembled ventilator at a vertical
angle of 35°.
10
9
11
7
2346 1215
8
12
