4.Warm-up State
￭ Warm-up state
The light fixture will enter a warm-up state for 20 seconds when it is
energized with AC100`240V for the first time: The three adjustable light
heads are switched off, the 12 function indicators will light gradually for
20 seconds; 20 seconds later, three heads will light and the light fixture is
ready to be set.
￭ Function indicator
When the light on standby mode detects the motion, four function
indicators showing the current level will keep light on for 5 seconds.
- 5 -
72ft
40ft
20ft
D2D
TEST
10mi n
5min
1min
DIS TMOD EDIM
3.Detection Range
Detection Range: around 72 ft/21m * 180 degrees (Max.)
180°0°
20ft/6m
10ft/3m
150°
80°
30°
40ft/12m
72ft/21m
72ft/21m
40ft/12m
20ft/6m
8.25ft
2.5m
