- 4 -
4.Remove the silicone plug amid
the Wiring Cover (G), then install
the Wiring Cover (G) on the junction
box and tight it with screw (C). Then
cover the hole with silicone plug.
5.Mount the light fixture (F) on
the Wiring Cover assembly,
tight it with screw (D)and cover
it with silicone plug(E).
OPERATION
1.Lamp Heads Adjustment
￭ The left and right lamps can be adjusted 180 degrees up or down.
The middle lamp can be adjusted 90 degrees up or down.
￭ The left and right lamps can be adjusted 90 degrees backward or
forward.
￭ The triangle bracket can be adjusted 45 degrees left or right.
2.Motion Sensor Adjustment
90°
180°
90°90°
45°45°
90°90°
￭ The sensor can be adjusted 90° degrees
left or right.
