ENGLISH 10
12 Technical data
Spray tank: Total volume
Max. fill volume
Approx. 7 l [1.85 gal]
6.0 l [1.59 gal]
Residual volume, (remaining liquid in tank that cannot be used) < 200 ml [6.8 oz]
Pump system SOLO Diaphragm pump
Operating pressure 2.5 bar [36 psi]
Permissible operating temperature 0
40 °C [32
104 °F]
Application volume (with standard spraying nozzle) 0.6 l – 1.6 l
[0.158
0.422 USgal]
Filter insert: Mesh gauge 0.8 mm [0.031"]
Filling screen: Mesh gauge 1.8 mm [0.071"]
Intake screen (stainless steel) Mesh gauge 0.35 mm [0.014"]
Weight: Ready for operation, empty, w/o battery
Ready for operation, with max. filling volume
2.1 kg [4.63 lbs]
8.2 kg [18.08 lbs]
Dimensions (without spray wand, battery height
and pressure hose):
Width
Depth
305 mm [12.0"]
345 mm [13.6"]
195 mm [7.7"]
Rechargeable battery (Li-Ion) Rated voltage
Capacity
11,1 V
2.5 Ah
Battery charger Input operating voltage
Frequency of operating voltage
Rated output voltage
Max. charging current
Protection type / protection class
100–240 V
AC 50/60 Hz
DC 12.6 V
1.5 A
IP 20 / II
Charging time with minimum initial battery charge
pprox. 1.9 h
Operating time with standard nozzle per charging cycle
(0.6L/min@2.5bar [0.158 USgal @36 psi] )
pprox. 2.8 h
Sound pressure level
1
L
Pe
according to EN ISO 3744 < 70 dB(A)
Sound power level
1
L
We
according to EN ISO 3744 < 70 dB(A)
Weighted effective acceleration
1
a
hv,e
according to EN ISO 5349 < 2.0 m/s
2
[78.7 "/s
2
]
1
In determining the above mentioned values regarding the acceleration of vibrations and sound, the
different operating conditions were weighted in accordance with the current standards.
