Solo 451 - Technical Specifications

Technical Specifications
ENGLISH 17
15. Technical Specifications
Mistblower 451
Engine type SOLO single cylinder two-stroke engine
Engine capacity cm
3
66.5
Bore / stroke mm 46 / 40
Max Engine power (ISO 8893) kW at rpm 2.1 / 5750
Fuel tank capacity l 1.8
Fuel mix ratio: with SOLO 2T Oil
with other two-stroke oils
1:50 (2%)
1:25 (4%)
Carburettor All-position diaphragm carburettor with
primer and integrated fuel pump
Air filter cartridge Paperstyle
Ignition Electronically controlled magneto
ignition, maintenance free
Total Formula Tank Capacity l 13 / 21 (Typ 451-02)
Nominal Formula Tank Capacity l 12 / 20 (Typ 451-02)
Strain funneled mesh size mm 0.55
Residual volume which the equipment cannoot properly apply
ml < 100
Strainer for accessory sets mesh size mm 0.32
Max. Blower Air Volume *) m
3
/h 1400
Weight m
net
kg
m
total
kg
11.8 / 12.0 (Typ 451-02)
25.0 / 33.1 (Typ 451-02)
Dimensions without Spray Tube mm hight: 690 / width: 550 / depth: 280
Permissible speed rpm 5600 ± 200
Maximum speed of the fan *) rpm 4300
Medium idling speed rpm 2200 ± 200
In determining the following values regarding the acceleration of vibrations and sound, the different
operating conditions were weighted in accordance with the current standards
Sound pressure level L
Pe
q
(EN ISO 3744) dB(A) 94 ± 2,5 dB(A)
Sound power level L
We
q
(EN ISO 3744) dB(A) 103 ± 2,5 dB(A)
Weighted effective acceleration a
hv
,
e
q
(EN ISO 5349) m/s
2
< 2 ± 1m/s
2
*) without Spray Tube
