5. Important Components
1. Tank lid / Filler basket with filter 11. Primer
2. Formula tank 12. Shoulder strap – quickcoupling
3. Formula outlet 13. Liquid tap
4. Spark plug 14. Spray tube
5. Carburetor adjustment screws 15. Spray nozzle
6. Muffler 16. Dosage sleeve
7. Starter handle 17. Throttle lever
8. Air filter cover 19. Stop switch
9. Fuel tank cap 20. Tank ventilation
10. Choke 21. Throttel control lock
