E S S E N T I A L S FOR LIFE
User
Manual
MODEL
GGSVD7
7kg
Vented
Dryer
V4

Other manuals for Solt GGSVD7

Questions and Answers

Summary

Welcome

Safety Instructions

Dryer Safety Warnings

Important safety warnings and cautions for operating the clothes dryer.

Fire Hazards and Lint Filter Safety

Fire Hazards

Identifies fabrics and materials unsuitable for tumble drying due to fire risk.

Cleaning the Lint Filter

Emphasizes the importance of cleaning the lint filter to improve dryer efficiency and prevent fire.

Operating Your Dryer - Filter and Fabric Care

Lint Filter Removal and Operation

Details on how to remove and re-insert the lint filter correctly.

Drying Capacity and Fabric Care

Guidance on dryer capacity and advice for drying different fabric types.

Technical Specifications

Appliance Specifications

Key technical details including capacity, power supply, and ratings.

Circuit Diagram

Visual representation of the dryer's electrical components and connections.

Your Vented Dryer Components

Component Identification

Diagram and list identifying the main parts of the vented dryer.

Control Panel Overview

Button and Indicator Functions

Explanation of the power, program, dryness, and other control panel buttons.

Before First Use

Power Source and Grounding

Instructions for connecting the dryer to a suitable power source.

Pre-Operation Precautions

Essential checks and precautions before operating the dryer for the first time.

Accessory Kit Components

Wall Hanging Kit Contents

Details and images of components included for wall hanging installation.

Installation Instructions

Power Source and Grounding

Recommendations for connecting the dryer to a grounded power outlet.

Wall Mounting Procedure

Step-by-step guide for securely wall mounting the dryer.

Operating Your Vented Dryer - Quick Start

Quick Start Guide

A step-by-step guide for quickly starting and operating the dryer.

Detailed Dryer Operation - Preparation and Settings

Preparation and Loading

Guidance on preparing clothes, checking the filter, and loading the dryer correctly.

Selecting Drying Settings

How to choose the appropriate drying program and dryness level.

Program Functions and Optional Features

Program and Dryness Level Options

Table detailing program types, capacities, and dryness levels available.

Optional Functions Explanation

Explanation of Anti-crease and Child Lock features.

General Operating Hints and Tips

Drying Guidelines and Best Practices

Advice on what not to dry, fabric care, and achieving best results.

Cleaning and Maintenance

Filter Cleaning Procedure

Step-by-step instructions for cleaning the lint filter after each use.

Inner Drum and Cabinet Cleaning

Guidance on cleaning the dryer's interior drum and exterior cabinet safely.

Troubleshooting Guide

Common Problems and Solutions

A table listing common dryer issues and their potential causes and solutions.

Error Codes and Support Information

Error Code Explanations and Actions

Information on error codes displayed by the dryer and recommended actions.

Customer Support and Parts

Details for obtaining replacement parts and contacting customer care.

Purchase Details Record

Recording Purchase Information

Fields for users to log store and product details for future reference.

Warranty Information

Australian Warranty Terms and Conditions

Outlines the terms and conditions of the product warranty for Australian customers.

Warranty Claim Process

Making a Warranty Claim

Steps and requirements for making a warranty claim, including contact information.

Overview

This document is a user manual for the Sôlt 7kg Vented Dryer, model GGSVD7.

Function Description:

The Sôlt 7kg Vented Dryer is designed for drying clothes, towels, and linen in a domestic environment. It operates by tumbling clothes in a drum while circulating heated air, with the moist air vented out. The dryer features various drying programs and dryness levels to accommodate different fabric types and desired outcomes. It also includes optional functions like Anti-Crease and Child Lock for enhanced usability and safety.

Important Technical Specifications:

  • Model: GGSVD7
  • Rated Capacity: 7.0kg (of dry clothing)
  • Power Supply: 220-240V~50Hz
  • Rated Power: 2000W
  • Motor Input Power: 200W
  • Heating Power: 1800W
  • Grade of Waterproof: IPX4
  • Dimensions (approximate, for wall mounting templates):
    • Horizontal screw position: 607mm wide
    • Vertical screw position: 835.5mm high
  • Circuit Diagram Components: Includes a plug, non-self-resetting thermal cut-out, heater, self-resetting temperature controller, capacitor, motor, temperature sensor, door switch, PCB, and filter.

Usage Features:

  • Control Panel: The control panel includes a Power button, Start/Pause button, Program selector (1 Hour, Synthetic, Cotton, Mixed Items), Dryness level selector (Light, Standard, Extra Dry), and Anti-Crease mode button.
  • Drying Programs:
    • Cotton: Offers Extra, Standard, and Light dryness options. Max capacity 7kg (80-90% remaining humidity for Extra, 60-70% for Standard).
    • Mixed Load: Offers Extra and Standard dryness options. Max capacity 7/3.5kg (70% remaining humidity for Extra, 60% for Standard).
    • Synthetics: Offers Extra and Standard dryness options. Max capacity 3.5kg (50% remaining humidity for Extra, 40% for Standard).
    • 1 Hour: A fixed 1-hour program, max capacity 1kg.
  • Dryness Levels: Light, Standard, and Extra Dry options are available for most programs, allowing users to choose the desired level of dryness.
  • Anti-Crease Function: Adds a short period of tumbling at the end of the drying program without heat to reduce creasing. Activated by pressing the Anti-Crease button.
  • Child Lock: Prevents accidental operation or changes to settings. Activated by simultaneously pressing the "Program" and "Dryness" buttons for 3 seconds. An LED indicator next to the lock symbol confirms activation.
  • Cool Down Cycle: The final cycle of all programs is a cool down cycle to reduce the temperature of clothes and prevent damage. The dryer will buzz once at the start of the cool-down and again at the end of the program.
  • Loading Guidelines:
    • Load the dryer to ½ to ⅔ capacity for faster drying and even air circulation.
    • For small loads, adding towels that won't lose fibers can help wet clothes dry more evenly.
    • Avoid over-drying to prevent creases and static charges.
    • Sort clothes by fabric type and similar drying times.
    • Check clothing care labels for suitability for tumble drying.
    • Do not dry items with vegetable oil, cooking oil, suntan oil, linseed oil, salad oil, lubrication oil, or grease, as these can ignite spontaneously.
    • Do not dry items cleaned with petrol/gasoline, industrial chemicals, dry-cleaning solvents, or other flammable substances.
    • Do not dry items containing foam rubber or rubber-backed articles.
    • Remove all objects from pockets before drying.
    • Ensure clothes are thoroughly spun before tumble drying.
    • Use fabric softener or conditioner to avoid static charge.
    • Avoid drying dark clothes with light-colored items to prevent lint transfer.
    • Separate lint-giving fabrics (towels, nappies, chenille) from lint-collecting fabrics (corduroy, synthetics, permanent press).
  • Installation:
    • Can be placed on the ground or wall-mounted.
    • Requires a dedicated, grounded AC power supply.
    • Minimum clearances: 80mm from the top to the ceiling, 10cm from the wall/cabinetry, and no obstacles within 1.5m of the front.
    • Wall mounting requires securing horizontal and vertical screw position templates and brackets to a stud or concrete wall. Expansion screw bolts are provided for concrete.
    • The control panel can be inverted for wall-mounted installations.
    • It is crucial to ensure the dryer is horizontally level for balanced operation.
    • Must be installed indoors, away from combustible surfaces, gas, or flammable materials.

Maintenance Features:

  • Lint Filter Cleaning:
    • The lint filter is located inside the door opening and must be cleaned after each and every load.
    • To clean, lift the plastic filter out, open it, wipe lint with a damp cloth, and click it closed before replacing.
    • Operating the dryer without a clean filter reduces efficiency, increases drying times, wastes energy, and poses a fire hazard.
    • A torn or damaged lint filter must be replaced immediately.
  • Inner Drum Cleaning:
    • Wipe the inner drum and cabinet with a soft, slightly damp cloth.
    • Do not use excessive water, scouring pads, abrasives, alcohol wipes, or harsh cleaning chemicals.
  • Periodic Inspection: It is recommended to have a qualified appliance technician inspect and clean the dryer periodically to avoid potential fire hazards.
  • Troubleshooting: The manual provides a troubleshooting guide for common issues like the dryer not starting (power, door, fuse issues) or clothes remaining wet (insufficient drying time, room temperature, blocked lint filter). Error codes (E1, E2, E3) related to internal temperature or sensor errors are also described with corresponding actions.
  • Parts and Support: Replacement lint filters and other spare parts can be purchased by contacting the local Customer Care team. Online help and a customer care phone number are provided.
