Solter Hellmet Devil - Adjustments of the Analog Filters; Darkening, DIN grade; Sensitivity; Delay

light dispersion and the uniformity of the filter's vision according to regulations.
The next three numbers indicate the European Regulation with which the filter complies.
ADJUSTMENTS OF THE ANALOG FILTERS
1 - Solar
2 - Regulations
3 - Welding Mode
4 - Darkening (DIN)
5 - CR2450 interchangeable battery
6 - Delay adjustment
7 - Sensitivity adjustment
8 - Arc sensors
9 -viewing area
Darkening, DIN grade.
The DIN degree setting will depend on the application from which we want to
protect and its power. DIN grade is the degree of darkness of the filter during
the welding process. Adjust with the wheel between 9 and 13.
Sensitivity
Adjusts the intensity of light necessary for the filter to go from the open state to the closed state (dark). In the MIN
position the sensitivity to light is low, in the MAX position the sensitivity to light is high.
9
