SOMFY Inteo SOLIRIS IB - Installation; Mounting the SOLIRIS IB; SOLIRIS IB Terminal Layout

SOLIRIS IB
2
2 x
Connect the wires to the termi-
nals of the connecting bracket
in accordance with the terminal
layout (chapter 2.2).
Press the safety cover onto the
back of the bracket then fit this
one on the recessed box.
To remove the safety cover, use a screw-
driver to press gently in the slot provided in-
side the terminal block.
Plug the SOLIRIS IB control
unit into the bracket,together
with the cover frame.
When setting (chapter 3) and
programming (chapter 4) is
completed,the cover plate can
be clipped onto the control unit.
Terminal layout2.2
C
L
N
Soliris IB connecting
Bracket
Terminal layout
Main Phase (L )
Main Neutral (N )
IB Bus common (C)
IB Bus Up ( )
IB Bus Down ( )
Common (C)
Sun sensor ( )
Wind sensor ( )
Rain sensor ( )
C
Mounting2.1
Soliris sensor
Rain sensor
Soliris IB
Centralis uno IB Centralis uno IB
3 x 0,75 mm
2
2 x 0,75 mm
2
4 x 0,75 mm
2
4 x 0,75 mm
2
3 x 0,75 mm
2
Supply
3 x 1,5 mm
2
Supply
3 x 1,5 mm
2
Supply
3 x 1,5 mm
2
Supply
3 x 1,5 mm
2
3 x 0,75 mm
2
3 x 0,75 mm
2
Centralis uno IB
4 x 0,75 mm
2
Supply
3 x 1,5 mm
2
We reserve the right to make changes due to technical improvements.
SOLIRIS IB is suitable for mounting in a 60 mm Ø concealed connection box or suitable surface mounting cap (Somfy accessories).
SUPPLY
230V 50Hz
Phase
Neutral
Earth
IB BUS line
DOWN :
UP :
Common :
C
+
N
L
N
LT motor
DOWN
PE
N
UP
C
L
N
C
Soliris sensor
Rain sensor
brown
blue
brown
blue
yellow/green
Soliris IBCentralis uno IB
C
+
N
L
N
LT motor
DOWN
PE
N
UP
Centralis uno IB
