7. Fit the wiring connector cover into the recess in the
speaker’s front panel. The cover should fit tightly but can
be removed and replaced if the speaker needs to be
disconnected (see figure 9).
8. Fit the grille onto the speaker (see figure 10).
FIGURE 9:
ATTACH THE
CONNECTOR COVER
FIGURE 10:
ATTACH THE GRILLE
UNLOCK
(towards rear
of speaker)
LOCK
(towards front
of speaker)
UNLOCK (toward rear of speaker)
LOCK (toward front of speaker)
FIGURE 11:
LOCK AND
UNLOCK
SLIDE LOCKS
TO PIVOT
SPEAKER
PIVOTING THE SPEAKER
You can rotate the speaker in the bracket to direct the sound
toward the listeners.
1. Unlock the slide locks on the speaker pivots by moving
them toward the rear of the speaker (see figure 11).
2. Rotate the speakers to the desired position.
3. Lock the slide locks by moving them toward the front of
the speaker.
LIMITED ONE (1) YEAR WARRANTY
Sonance warrants to the first end-user purchaser that this
Sonance-brand product (“Product”), when purchased from
an authorized Sonance Dealer/Distributor, will be free from
defective workmanship and materials for one (1) year after
the date of original purchase of the Product. Sonance will at
its option and expense either repair the defect or replace
the Product with a new or remanufactured Product or a
reasonable equivalent.
EXCLUSIONS
TO THE EXTENT PERMITTED BY LAW, THE WARRANTY
SET FORTH ABOVE IS IN LIEU OF, AND EXCLUSIVE OF,
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND
IS THE SOLE AND EXCLUSIVE WARRANTY PROVIDED
BY SONANCE. ALL OTHER EXPRESS AND IMPLIED
WARRANTIES, INCLUDING THE IMPLIED WARRANTIES
OF MERCHANTABILITY, IMPLIED WARRANTY OF FITNESS
FOR USE, AND IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE ARE SPECIFICALLY EXCLUDED.
No one is authorized to make or modify any warranties on
behalf of Sonance. The warranty stated above is the sole
and exclusive remedy and Sonance’s performance shall
constitute full and final satisfaction of all obligations, liabilities
and claims with respect to the Product. IN ANY EVENT,
SONANCE SHALL NOT BE LIABLE FOR CONSEQUENTIAL,
INCIDENTAL, ECONOMIC, PROPERTY, BODILY INJURY,
OR PERSONAL INJURY DAMAGES ARISING FROM THE
PRODUCT, ANY BREACH OF THIS WARRANTY
OR OTHERWISE.
This warranty statement gives you specific legal rights,
and you may have other rights which vary from state to
state. Some states do not allow the exclusion of implied
warranties or limitations of remedies, so the above
exclusions and limitations may not apply. If your state does
not allow disclaimer of implied warranties, the duration of
such implied warranties is limited to period of Sonance’s
express warranty.
Your Product Model & Description: Sonance MAGO6V2 Speakers.
Additional Limitations and Exclusions from Warranty
Coverage: The warranty described above is non-transferable,
applies only to the initial installation of the Product, does not
include installation of any repaired or replaced Product, does
not include damage to allied or associated equipment which
may result for any reason from use with this Product, and
does not include labor or parts caused by accident, disaster,
negligence, improper installation, misuse (e.g. overdriving
the amplifier or speaker, excessive heat or cold or humidity,
outdoor installation), or from service or repair which has not
been authorized by Sonance.
Obtaining Authorized Service: To qualify for the warranty,
you must contact your authorized Sonance Dealer/Installer
or call Sonance Customer Service at (949) 492-7777, must
obtain a return merchandise number (RMA), and must
deliver the Product to Sonance shipping prepaid during the
warranty period, together with the original sales receipt, or
invoice or other satisfactory proof of purchase.
©2019 Sonance. All rights reserved. Sonance and
FastMount are registered trademarks of Dana Innovations.
Due to continuous product improvement, all features and
specifications are subject to change without notice.
For the latest Sonance product specification information visit
our website: www.sonance.com
IMPORTANT: BE SURE NOT TO LET ANY STRAY ‘+’ AND ‘–’
WIRES TOUCH EACH OTHER. TOUCHING WIRES CAN CAUSE
A SHORT- CIRCUIT THAT COULD DAMAGE YOUR AMPLIFIER.
991 Calle Amanecer
San Clemente, CA 92673 USA
(949) 492-7777 • FAX: (949) 361-5151
www.sonance.com
• The spring connectors can accept wire up to 14 gauge.
• Double-check that you connected all of the wires
properly (amplifier ‘+’ to speaker ‘+’; amplifier ‘–’
to speaker ‘–’) at all connections.
SPECIFICATIONS
MAGO6V2 Speakers
Tweeter: 1” (25mm) cloth dome, Ferrofluid cooled,
in acoustic back chamber
Woofer: 6.5” (165mm) glass fiber cone
with a Santoprene surround
Frequency Response: 65Hz - 30kHz
±
3dB
Impedance: 8 ohms nominal; 6 ohms minimum
Power Handling: 5 watts minimum; 80 watts maximum
Sensitivity: 89dB SPL (2.83V/1 meter)
Environmental: Conforms to Mil Spec 810 for humidity, salt spray,
temperature and UV, IP-66 waterproof rating
Environment Temp: -13º - 149ºF (-25ºC - 65ºC)
Dimensions (WxHxD): 7.51” x 12.14” x 6.86” (191mm x 308mm x 174mm)
Grille: Perforated aluminum
Shipping Weight: 14 lbs. (6.4kg) pair
08.01.19
