SonarPhone SP200 - Product Specifications

x Compatible with Apple and Android Smartphones and Tablets
x Digital Depth Indicator
x Water Temperature
x Automatic Ranging
x Fish Icon
x Depth and Fish Alarm
x Zoom Bottom Track
x Keel Offset Setting
x Noise Rejection
x Surface Clarity
x Battery Indicator
x WiFi Wireless Link
IMPORTANT: Your mobile device must have a display resolution of
at least 320 x 320 pixels in order for the SonarPhone app to
function properly.
SP100 Specifications
x Depth Range Max: 120 feet (40M)
x Depth Range Min: 2 feet (0.6M)
x Sonar Frequency: 125 kHz Single Beam
x Cone Angle: 30 Degrees
x Sonar Power: 3.7V Rechargeable Battery
x Audible Alarms: Fish, Shallow, Low Battery
x Operational: -20 — +80°C
x Wireless distance: 100 Yards (90M)
SP200/SP300 Specifications
x Depth Range Max: 240 feet (73M)
x Depth Range Min: 2 feet (0.6M)
x Sonar Frequency: 200/83KHz Duel Beam
x Cone Angles: Dual Beam 20 or 40 Degree
x Sonar Power: 12V DC - 2.5mA Draw
x Audible Alarms: Fish, Shallow, Low Battery
x Operational: -20 — +80°C
x Wireless distance: 100 Yards (90M)
