f) dimensions ...................................................................................................... 330 x 235 x 120 mm
g) meter weight ......................................................PAT-800 approx. 4.05kg, PAT-805 approx. 4,75kg
h) storage temperature...................................................................................................... –20...+70C
i) operating temperature ....................................................................................................... 0...+40C
j) humidity ............................................................................................................................ 20…80%
k) nominal temperature ..................................................................................................... +20...+25C
l) reference humidity ............................................................................................................ 40…60%
m) display ...................................................................................................................... LCD, segment
n) memory of measurement results ....................................................................................... 990 cells
o) data transmission................................................................................................................ USB 2.0
p) quality standard .......................... development, design and manufacturing are ISO 9001 compliant
q) the product meets the EMC requirements acc. to ......... EN 61326-1:2009 and EN 61326-2-2:2006
Note:
During the measurement of PE continuity with PE 10/25 current the meter
may produce interference with values exceeding allowable limits defined in
EN 61326-1 and cause interference in other devices.
11.2 Standard equipment
Standard set of equipment supplied by the manufacturer includes:
 power lead 1pc – WAPRZZAS1
 test lead banana/banana, black 1.2m 1pc – WAPRZ1X2BLBB2X5 (WAPRZ1X2BLBB for PAT-
800)
 black crocodile clip 1kV 1pc – WAKROBL30K03 (WAKROBL20K01 for PAT-800)
 1kV probe - black 1pc – WASONBLOGB3
 USB cable – WAPRZUSB
 fuse 0314 015.VXP 15A 250VAC 6.3x32mm Littlefuse 2 pcs – WAPOZB15PAT
 cover – WAFUTL5
 operating manual
11.3 Optional accessories
Additionally, the following items that are not included in the scope of standard equipment can be
purchased from the manufacturer or the distributors:
 barcode stickers
 PASS stickers (roll - 50 pieces of stickers)
 FAIL stickers (roll - 50 pieces of stickers)
 barcode stickers (roll - 100 stickers)
 1.2 m double-wire lead (10/25A) U1/I1 1pc (PAT-805) – WAPRZ1X2DZBB1
 1.2 m double-wire lead (10/25A) U2/I2 1pc (PAT-805) – WAPRZ1X2DZBB2
 power probe Sonel 1pc (PAT-805) – WASONSPGB1
 Kelvin crocodile clip 1pc (PAT-805) – WAKROKELK06
 black crocodile clip 1kV 1pc – WAKROBL20K01
 1kV probe -black 1pc – WASONBLOGB3
 test lead banana/banana, black 1.2m 1pc– WAPRZ1X2BLBB
 cable - adapter Shuko / IEC (for testing extensions) – WAADAPATIEC1
 three phase socket adapter 16A* – WAADAPAT16P
 three phase socket adapter 16A, switchable** – WAADAPAT16PR
 three phase socket adapter 32A* – WAADAPAT32P
 three phase socket adapter 32A, switchable**– WAADAPAT32PR
 adapter for industrial sockets 16A*** – WAADAPAT16F1
