Chapter 2 – Echo Express SE II Description
Echo Express SE II Power Adapter
1 – Power Adapter
Connect this to the Echo Express SE
II chassis’ power port. Note that the
power indicator on top lights when
the adapter is connected to AC power.
2 – Power Cord
Connect this between a power outlet
and the power adapter. Note that
the power cord included with your
product may appear different than
the one pictured here, depending on
where the product was purchased.
Thunderbolt Connector Lock
This lock secures Thunderbolt connectors
plugged into the Echo Express SE II’s
Thunderbolt ports to prevent accidental
cable disconnection. This lock is not
compatible with optical Thunderbolt
cables.
Thunderbolt Cable
Connect this cable between the Echo
chassis and your computer (or other
Thunderbolt device in the chain
connected to the computer).
